You should see an icon representing each of your attached monitors.Choose the monitor you want to calibrate by clicking on it. Underneaththe monitor icon is a drop down box where you specify the type ofdisplay you have:
The kernel driver listed is the correct one for i1Profiler. The purpose of it is to create color profiles for monitors, printers, digital cameras, digital projectors, scanners, and anything else you can attach to a computer that captures, emits, or prints color. Go back to ColorMunki Software and you will see serial number and registration code. I1Display Pro: 1. Plug in i1 Display Pro device to your computer 2. Open i1Profiler 3. Click on Registration 4. Click on Web Registration (it will go straight to your internet browser) 5. Go back to i1Profiler and you will see serial number and registration.
i1Profiler will attempt to detect this for you, but in ourexperience, it's best to manually choose the right one. I have chosenWide Gamut CCFL as both my attached monitors are wide gamut monitorswith a fluorescent back light source.
The options are:
- Generic - Try this if you really don't know your monitor's type
- CCFL - Choose this is you have a standard gamut LCD with fluorescent backlighting
- Wide Gamut CCFL - If you have a wide gamut model with fluorescent backlighting
- White LED - If your monitor is LED backlit and uses white LEDs (this is nearly all standard LED monitors)
- RGB LED - If your monitor is LED backlit and uses RGB LEDs
- Projector - If you're calibrating a digital projector
- OLED - Organic Light Emitting Diode - if you're lucky enough to have an OLED display, choose this.
- Plasma - For plasma TV displays
- RG Phosphor - We've never needed to use this one!
If you don't know, check your monitor's manual - it's usuallymentioned in the specifications section.If you can't work it out, youcan ask us and we can try and find out for you, but it's worthexperimenting with these if you get any weird visual results postcalibration as this is the area most likely to go wrong.
X-Rite i1Profiler 3.2.1
Release Notes
Attention: If you are using an i1Pro 1 (Rev. A - Rev. D) do not install this update. i1Profiler v3.2 (and later) does not support the i1Pro 1.
All other i1 devices (including the i1Display Pro) continue to be supported.
New for the 3.2.1 Release
The following features and improvements have been added for this release:
General Application
New Features
I1profiler Software For Mac
Adds support for the i1Pro 3 PLUS spectrophotometer and the i1iO 3 PLUS automated scanning table in the Print Quality workflow.
Adds support for the IDEAlliance LFP target in the Print Quality workflow for use with the i1Pro 3 PLUS.
Adds support for FOGRA 53 and 54 reference measurements.
Drops support for Microsoft® Windows 7 operating system.
Bug Fixes
Fixes issue where the Start Measurement button in the display profiling workflow was hidden on some systems.
Fixes issue where Japan Color targets in the Print Quality workflow could only be read in spot mode.
Fixes issue where highlighting of the largest ∆E* patches in the Display and Printer Quality workflows was not working.
Minimum suggested hardware requirements
Macintosh®:
macOS 10.13.x through macOS 10.15.x
All Operating Systems should have the latest updates installed
2GB RAM
Intel® Core 2 Duo Processor
2GB of available disk space
Powered USB Port
Monitor resolution of 1024x768 pixels or higher
Dual display support requires either 2 video cards or a dual head video card that supports dual video LUTs being loaded
Latest drivers for video card installed
High-speed Internet connection required for software install, download and automatic software update
User must have Administrator rights to install and uninstall the application
Windows®:
Microsoft® Windows 8.1® 32 or 64 bit
Microsoft® Windows 10® 32 or 64 bit
I1profiler Manual
All Operating Systems should have the latest updates and Service Packs installed
2GB RAM
Intel® Core 2 Duo or AMD Athlon™ 64 X2 or better CPU
2GB of available disk space
Powered USB Port
Monitor resolution of 1024x768 pixels or higher
Dual display support requires either 2 video cards or a dual head video card that supports dual video LUTs being loaded
Latest drivers for video card installed
Network adaptor installed and driver loaded
High-speed Internet connection required for software install, download and automatic software update
User must have Administrator rights to install and uninstall the application
Known Issues
The measurement algorithm used for transmissive scanning of the light box does not have error checking. Please verify all measurements visually on screen before proceeding to the next workflow step.
The i1Profiler Tray application (Mac only) has a memory leak when doing ambient monitoring. Restart the tray periodically to release system memory.
There is a refresh issue when scrolling within the gamut view window. If the screen does not refresh correctly, click anywhere within the application window and the gamut view will update.
The Reference Files for the ColorChecker SG and ColorChecker 24 for scanner profiling have been updated. These new reference files apply well to ColorChecker SG and 24 charts manufactured after November 2014. For ColorChecker editions prior to November 2014, please use the former Reference Files, which can be downloaded from www.xritephoto.com, including instructions how to replace and apply them in i1Profiler.
Profiling and optimizing profiles with very large patch sets (>3000) will require a very large amount of RAM. If profiling fails, reduce the amount of patches in the test chart.
Monitor calibration does not work when multiple monitors are in mirror mode (this issue affects Windows® installations only.)
i1Profiler does not support the calibration of displays connected via AirPlay.
If you have problems loading the display profile after it has been created or if the system cannot load the display LUTs, turn off Automatic Display Control (ADC) on the measurement page and try again.
i1Profiler uses OpenGL to display the profile’s 3D gamut. If you encounter a problem with the gamut preview, make sure that your video card drivers are up to date.
i1Profiler can import CGATS measurement files from other applications. However, the color engine has been optimized to work with the patch sets generated within i1Profiler. The profile quality from profiles made entirely within the i1Profiler workflow will exceed profiles made from legacy charts and measurements. In the case of CMYK+N profiles, some legacy patch sets may not even build a profile successfully. It is strongly recommended that users build new charts within i1Profiler for CMYK+N profiling.
If you are using Ambient Smart Light Control when making your display profile, expect to get higher Delta E values in Display QA. This function optimizes profiles for visual appearance based on measured ambient conditions not for minimal Delta E.
The i1ProfilerTray application looks for connected displays at launch. If you disconnect or connect a display, the i1ProfilerTray will not see the change until it is restarted, the user logs out or the system is restarted. On Windows the i1ProfilerTray can be restarted from the ProgramsStartup menu, on Mac, the tray is located in the same folder as the i1Profiler application.
The application may lose its connection to a measurement device if the computer goes into sleep or hibernation mode. If this happens, disconnect and reconnect the device to restore the connection.
Installation of older applications that use the previous version of X-Rite Device Services may cause i1Profiler to not connect with devices or to not launch. If this occurs, reinstall i1Profiler to restore the latest Device Services.
If you encounter any problems connecting to your measurement device, please disconnect and reconnect the device to restore the connection.
Make sure your i1iSis power button is on when you connect the USB cable. If you connect with the button off, then turn the power on, the i1iSis will not be seen.
The i1iO device does not support single row charts.
You cannot measure an optimization test chart that contains patches extracted from an image if you are using an i1iO or i1iO2.
Change History
Version 3.2.0
New Features
Adds support for the i1Pro 3 spectrophotometer and the i1iO 3 automated scanning table.
Removes all support for revisions A through D of the i1Pro spectrophotometer (i1Pro 1). The i1Pro 1 has reached end of life and is no longer supported for service.
Bug Fixes
Fixes multiple bugs in the Printer Quality workflow:
Fixes issue where reports could not be generated for IDEAlliance and Fogra targets.
Fixes issue where ISO 12647-7 test criteria were not reported correctly.
Fixes issue where Japan Color targets could not be analyzed using live measurements.
Fixes issue where profiles created with non-D50 illuminants were built incorrectly.
Fixes issue where Measure Reference workflows could not be saved for CMYK+N data.
Version 3.1.1
New Features
Adds support for macOS 10.15 (Catalina).
Improves scanning quality and reliability when creating transmissive printer profiles with the i1Pro 3 PLUS.
Adds ink limiting control when creating CMYK transmissive profiles.
Adds the ability to drag and drop assets in the transmissive workflow.
Adds new Hasp dongle driver with 64-bit support (macOS).
Bug Fixes
Fixes issue where i1Profiler crashes when entering the ColorChecker Proof workflow.
Fixes issue where spot measurements are not displayed correctly in transmissive workflow.
Version 3.1
New Features
Adds support for the iDisplay PLUS device. This device can accurately measure displays with luminance up to 2000 nits.
Adds support for the BT.1886 EOTF (Gamma curve). This curve is the recommended standard for HDTV.
Version 3.0
New Features
Adds support for the i1Pro 3 PLUS large aperture spectrophotometer.
- Large 8 mm aperture, to support a wide range of substrates.
- Polarization filter (M3) to reduce specular effects on fabrics, ceramics, & glossy media.
- Captures M0, M1 and M2 in a single pass.
- Full spectrum LED light source.
-Measures up to 5k cd/m2 for ultra-bright displays
Adds support for the i1iO 3 Automated Scanning Table
- Utilizes the i1Pro 3 PLUS features to allow measurement of a wider variety of substrates.
- Optional z-axis spacers allow measurement of very thick materials.
Introduces the ability to create ICC profiles for transmissive media; clear, translucent and textile.
Adds support for the ECG test chart and better support for patch sets created by third party applications.
Bug Fixes
Fixes issue where EPS files created for CMYK+N test charts were corrupted on Mac.
Fixes issue where i1Profiler Tray application will not launch on some MacOS systems.
Version 1.8.3
New Features
None
Bug Fixes
Fixed an issue where the application would not install on Windows systems.
Version 1.8.2
New Features
Added support for macOS 10.14.x (Mojave).
Bug Fixes
Fixed issue where users could not load files into Data Analysis (Japanese Only.)
Improved handling of permissions dialogs (macOS Mojave only.)
Version 1.8.1
New Features
Added the ability to restart X-Rite Device Services directly from the i1Profiler application. This will help users restore their connection to a measurement device without restarting their system.
Version 1.8.0
New Features
Made the i1Profiler and i1Profiler Tray applications 64-bit native to comply with future macOS updates.
Added the ability to make iccMAX compatible profiles. This is a version 4 profile with an iccMax profile embedded..
Updated ICC version 4 profiles to the 4.3 specification.
Added support for the Japan Color Control Strip for i1iSis
Reworked the entire Japan Color Print Quality module for correct reporting and validation of the Japan Color standard.
General UI improvements to better show when measurements and profiles have been successfully completed.
Improved the spectral curve display for all lighting measurements.
Improved reporting of display Uniformity results by changing to ∆E method.
Bug Fixes
Fixed issue where the Print button for RGB printer test charts was not working on some Windows systems.
Fixed issue where wrong patches were being shown for Flare Correction in display.
Fixed issue where i1Profiler did not calculate XYZ correctly for illuminants other than D50.
Fixed issue where certain device values in CGATS measurements would cause profiling to fail.
Fixed issue where the black width setting was not working when creating device-link profiles.
Fixed issue where i1Profiler could not correctly profile a system with two identical displays attached.
Version 1.7.2 (Mac Only Release)
Made a change to allow the default linear profile to be loaded at the start of measurement.
This issue affected macOS 10.13 (High Sierra) systems only.
Version 1.7.1
What Is I1profiler
Fixed an issue where the Print button for RGB printer profiling was not working.
Fixed an issue where the Compare Profile button for gamut viewing was missing.
Fixed an issue where the Lab values of extra channels for CMYK+N profiling was not working correctly in some languages.
Version 1.7.0
Added support for High DPI displays
Fixed an issue where the XRGA to GMDI conversion for certain reference files in Printer QA was not being handled correctly.
Fixed an issue where multi-page targets, formatted on a single sheet for the i1iO and i1Pro could not be read.
Fixed an issue where device-link profile settings were not working correctly.
Open Source and 3rd Party Software
All Open Source and 3rd Party License agreements and credits are located in the following locations:
Windows: Program Folder/Credits
Mac: Application package/Contents/Resources/Credits
